Product Number
Series
Type
Size
Tolerance
Resistance Range
Power Rating
TCR
Image SPEC Product Number Series Type Size Tolerance Resistance Range Power Rating TCR
WK25V WK25V Thick Film High Voltage Chip Resistor 2512 (6432) ±0.5%,1%,2%,5% 47Ω~51MΩ 1W ≦±100,≦±200,+500~-200
WK20V WK20V Thick Film High Voltage Chip Resistor 2010 (5025) ±0.5%,1%,2%,5% 47Ω~51MΩ 1/2W ≦±100,≦±200
WK12V WK12V Thick Film High Voltage Chip Resistor 1206 (3216) ±0.5%,1%,2%,5% 47Ω~51MΩ 1/4W ≦±100,≦±200
WK08V WK08V Thick Film High Voltage Chip Resistor 0805 (2012) ±0.5%,1%,2%,5% 47Ω~51MΩ 1/8W ≦±100,≦±200
WK06V WK06V Thick Film High Voltage Chip Resistor 0603 (1608) ±0.5%,1%,2%,5% 47Ω~10MΩ 1/10W ≦±100,≦±200
WF25V WF25V Thick Film High Voltage Chip Resistor 2512 (6432) ±1%,5% 100KΩ~10MΩ 1W ≦±100
WF20V WF20V Thick Film High Voltage Chip Resistor 2010 (5025) ±1%,5% 100KΩ~10MΩ 1/2W ≦±100
WF12V WF12V Thick Film High Voltage Chip Resistor 1206 (3216) ±1%,5% 100KΩ~10MΩ 1/4W ≦±100
WF08V WF08V Thick Film High Voltage Chip Resistor 0805 (2012) ±1%,5% 68KΩ~10MΩ 1/8W ≦±100
SR10X SR10X Thick Film High Grade Anti-Sulfuration Chip Resistor 1210 (3225) ±1%,5% 0Ω,1Ω~10MΩ 1/2W ≦±100,≦±200,-200~+400
SR12X SR12X Thick Film High Grade Anti-Sulfuration Chip Resistor 1206 (3216) ±1%,5% 0Ω,1Ω~10MΩ 1/4W ≦±100,≦±200,-200~+400
SR08X SR08X Thick Film High Grade Anti-Sulfuration Chip Resistor 0805 (2012) ±1%,5% 0Ω,1Ω~10MΩ 1/4W ≦±100,≦±200,-200~+400
SR06X SR06X Thick Film High Grade Anti-Sulfuration Chip Resistor 0603 (1608) ±1%,5% 0Ω,1Ω~10MΩ 1/10W ≦±100,≦±200,-200~+400
SR04X SR04X Thick Film High Grade Anti-Sulfuration Chip Resistor 0402 (1005) ±1%,5% 0Ω,1Ω~10MΩ 1/10W ≦±100,≦±200,-200~+400
SR20X SR20X Thick Film High Grade Anti-Sulfuration Chip Resistor 2010 (5025) ±1%,5% 0Ω,1Ω~10MΩ 3/4W ≦±100,≦±200
